Optika IM-300LD2 Inverted LED fluorescence/phase contrast microscope, 400x, IOS LWD PLAN, B&G filter set

€7.530,00 excl. VAT

Estimated delivery time: 5-7 weeks

The Optika IM-300LD2 is an inverted trinocular LED fluorescence microscope for live cell culture work in brightfield, phase contrast, and fluorescence. It carries IOS LWD W-PLAN PH objectives at 10x, 20x, and 40x, and the condenser extends its working distance up to 135 mm for tall culture vessels. The 4-position fluorescence attachment ships with blue and green LED Fluorescence Cubes installed, each running over 65000 hours without lamp replacement. It suits life science laboratories that want LED fluorescence convenience alongside inverted brightfield and phase contrast observation.

Inverted LED Fluorescence Microscope with Blue and Green Cubes Included

The Optika IM-300LD2 brings LED fluorescence to an inverted stand for cell culture observation, with blue and green LED Fluorescence Cubes included as standard on a 4-position attachment. The condenser extends its working distance up to 135 mm, and a phase contrast slider adds brightfield and phase contrast on the same stand.

Blue and green LED Fluorescence Cubes included, 4-position attachment
Each LED cube runs over 65000 hours without lamp replacement
Condenser working distance extendable up to 135 mm for tall culture vessels
IOS LWD W-PLAN PH objectives at 10x, 20x, and 40x for brightfield and phase contrast
Suited to inverted cell culture LED fluorescence workflows

Optika IM-300LD2 Inverted Trinocular LED Fluorescence Microscope

The Optika IM-300LD2 is an inverted trinocular microscope from the IM-300 series, built around interchangeable LED Fluorescence Cubes for cell culture fluorescence work.

IOS LWD W-PLAN PH objectives cover brightfield and phase contrast observation, with an extendable working distance condenser for tall culture vessels.

LED Fluorescence with Blue and Green Cubes Included

The 4-position fluorescence attachment ships with blue and green LED Fluorescence Cubes installed. Each cube runs at 3.6 W with brightness control and a lifetime over 65000 hours, without warm-up delay or lamp replacement.

IOS LWD W-PLAN PH Objectives

The objective set covers 10x, 20x, and 40x, infinity corrected and anti-fungus treated with a 45 mm parfocal distance, giving 100x to 400x total magnification.

Extendable Long Working Distance Condenser

The Abbe condenser, N.A. 0.30, has a standard 72 mm working distance that extends up to 135 mm, with a phase contrast slider (BF, 4x/10x, 20x/40x).

X-LED8 Transmitted Illumination

The X-LED8 light source covers the transmitted brightfield and phase contrast light path at 8 W with manual brightness control.

Ideal Applications

The IM-300LD2 suits laboratories that need inverted LED fluorescence alongside brightfield and phase contrast.

Live cell culture fluorescence imaging
Immunofluorescence with blue and green fluorochromes
Phase contrast observation of unstained cell cultures
Research applications needing tall culture vessel compatibility
Laboratories that want to avoid mercury lamp maintenance

Choose the IM-300LD2 when:

You want LED fluorescence without lamp warm-up or replacement
You need an extendable working distance condenser for tall vessels
You need brightfield, phase contrast, and fluorescence on one inverted stand
You want blue and green cube coverage included as standard

Optika Value Proposition

The Optika IM-300LD2 combines IOS LWD W-PLAN PH optics with LED fluorescence cubes included as standard, on an inverted trinocular stand with an extendable long working distance condenser.

Technical specifications – IM-300LD2

Specification	IM-300LD2
Type	Inverted, aluminum die-cast
Head	Trinocular, Siedentopf, split ratio 100/0 – 50/50, 45 degree inclination
Eyepieces	PL 10x, field number 22 mm, high eyepoint, retractable protections
Objectives	IOS LWD W-PLAN PH 10x, 20x, 40x, anti-fungus treated
Stage	Fixed, 250×160 mm, glass and metal round inserts
Condenser	Abbe, N.A. 0.30, LWD 72 mm extendable up to 135 mm, phase contrast slider
Transmitted illumination	X-LED8, 8 W, manual brightness control
Fluorescence attachment	4 positions, 2 blue and green LED Fluorescence Cubes included
Blue LED cube (included)	Excitation 455-495 nm, dichroic 500 nm, emission 510LP nm
Green LED cube (included)	Excitation 510-550 nm, dichroic 570 nm, emission 575LP nm
Fluorescence light source	LED Fluorescence Cube, 3.6 W, lifetime over 65000 hours, brightness control
Product weight	10.5 kg

Options and Accessories – IM-300LD2

The IM-300LD2 ships with IOS LWD W-PLAN PH 10x, 20x, and 40x objectives and blue and green LED Fluorescence Cubes as standard. Additional accessories extend the system.

Mechanical stage, 250×230 mm, X-Y translation range 120×80 mm (optional)
Metallic interchangeable inserts for slides, Petri dishes, Terasaki, and multi-well plates (optional)
Holder for 2 slides (optional)
Holder for Utermohl chamber (optional)
