OHAUS FC5720R Refrigerated Multipurpose Centrifuge – Ultra-High Speed with Precision Cooling

The OHAUS FC5720R, part of the Frontier 5000 Multi-Pro Series, is a refrigerated multipurpose centrifuge designed for the most demanding laboratory applications. With a speed range of 200 to 20,000 rpm, reaching a maximum RCF of 38,007 × g, it delivers exceptional performance for protocols such as DNA/RNA isolation, protein purification, blood processing, and other high-speed separations.

This model has been transitioned to R290, a natural propane-based refrigerant with a low Global Warming Potential. The change keeps this centrifuge ahead of the EU F-gas Regulation 2024/573 and the US EPA SNAP phase-down of high-GWP refrigerants such as R452A, while matching the original stricter timeline rather than the extended deadline. The refrigeration circuit is hermetically sealed and complies with IEC 61010-2-011, the safety standard for laboratory equipment using flammable refrigerants, so operators keep full protection even in the unlikely event of a rotor failure or ignition risk.

The FC5720R features a powerful, brushless motor and a CFC-free refrigeration system that ensures accurate temperature control from –20 °C to +40 °C, with rapid pre-cooling to 4 °C in less than 10 minutes. This protects temperature-sensitive samples while enhancing workflow efficiency. Its stainless steel centrifuge chamber is corrosion-resistant, and built-in safety features include automatic rotor recognition, imbalance detection, motorized lid lock, and over-speed protection.

An intuitive backlit LCD display and rotary knob make operation simple. The unit supports 99 memory programs, 10 acceleration and 10 braking profiles, with run times from 10 seconds to 99 hours 59 minutes, or continuous mode. A Quick Spin function is also available.

The FC5720R is supplied without a rotor, allowing flexible setup with a broad selection of compatible angle and swing-out rotors. It supports sample volumes up to 4 × 200 mL, providing adaptability across a range of lab applications. Despite its performance, it operates quietly at ≤ 60 ± 2 dB(A) and fits into compact lab spaces with dimensions of 712 × 361 × 407 mm and a weight of 71 kg.

Key Features:

• Speed Range: 200–20,000 rpm (up to 38,007 × g)

• Temperature Control: –20 °C to +40 °C; 4 °C pre-cool in under 10 min

• Programmability: 99 memory programs; 10 accel/decel profiles; Quick Spin

• Safety Features: Rotor recognition, lid lock, over-speed and imbalance protection

• Rotor Compatibility: Multiple options up to 4 × 200 mL (rotor not included)

• Noise Level: ≤ 60 ± 2 dB(A)

• Construction: Stainless steel chamber

• Power Supply: 1.1 kW, 230 V

• Dimensions: 712 × 361 × 407 mm

• Weight: 71 kg

The OHAUS FC5720R is a high-capacity, high-speed multipurpose centrifuge that combines precise temperature control with flexible rotor options for demanding lab needs.
