ISF-7200R Floor Standing Refrigerated Shaking Incubator
€9.350,00 excl. VAT
- Type: Floor-standing refrigerated shaker
- Motion: Orbital, 50.8 mm large orbit
- Temp. range: Ambient –20 °C (min. 4 °C) to 80 °C
- Max speed: 300 RPM
- Highlights: Large 270 L chamber, five 6 L flasks capacity
Jeiotech ISF-7200R Floor Standing Refrigerated Shaking Incubator – Large Orbit Precision with Cooling for Biotech Labs
The Jeiotech ISF-7200R is a powerful floor-standing refrigerated shaking incubator designed for large-scale biotech, fermentation, and cell culture applications. Its spacious 270 L chamber accommodates up to five 6 L Erlenmeyer flasks, delivering excellent capacity for high-volume experimental workflows requiring sub-ambient temperature control.
Temperature is precisely controlled from Ambient –20 °C (minimum 4 °C) to 80 °C, making it suitable for processes needing low-temperature incubation. Its orbital shaking motion features a large 50.8 mm orbit, ensuring exceptional mixing and oxygen transfer for cultures in large flasks. The unit reaches shaking speeds up to 300 RPM, maintaining stability even under significant loads thanks to its direct drive (DD) motor and patented triple cam system.
The ISF-7200R offers user-friendly operation through a full-color touchscreen, programmable modes, and real-time status display. Safety is maximized with electronic and mechanical over-temperature protection, soft start/stop shaking, and overcurrent protection. The glide-down front door and pull-out platform make handling heavy flasks safe and easy. Optional LC GreenBox integration provides remote monitoring and alarms via a mobile app, adding further convenience for busy labs.
Key Features Summary:
-
Floor-standing refrigerated shaking incubator for high-volume use
-
Temperature range: Ambient –20 °C (minimum 4 °C) to 80 °C
-
Large orbital motion (50.8 mm) for enhanced aeration
-
Maximum speed: 300 RPM
-
270 L chamber fits up to five 6 L flasks
-
Direct drive motor with 5-year warranty ensures smooth operation under load
-
Color touchscreen with programmable modes and safety alarms
-
Optional LC GreenBox for mobile monitoring and notifications
Warranty: 1 year
Lead time: if on stock: 2 weeks. If not on stock 10 weeks
| Specification | Details |
|---|---|
| Model | ISF-7200R |
| Type | Floor-standing refrigerated shaking incubator |
| Motion Type | Orbital |
| Shaking Speed Range | 30–300 RPM |
| Shaking Orbit | 50.8 mm (2 inches) |
| Max Load per Platform | 20 kg at 300 RPM, 35 kg at 200 RPM |
| Temperature Range | Ambient –20 °C (minimum 4 °C) to 80 °C |
| Temperature Stability | ±0.1 °C |
| Chamber Volume | 270 L (9.5 cu. ft.) |
| Platform Size (W × D) | 755 × 520 mm |
| Interior Dimensions (W × D × H) | 894 × 634 × 480 mm |
| Timer | Countdown up to 999 hr 59 min |
| Touchscreen Control | Yes – Color LCD display |
| Over-Temp Protection | Dual system (electronic & mechanical) |
| Refrigeration System | Built-in, 1/6 HP |
| Monitoring via App | Yes – with optional LC GreenBox |
| Weight (Net) | 295 kg |
| Power Requirements | 230V, 50/60Hz, 5.6A |
| Warranty | 2 years general / 5 years for DD motor |
Optional Accessories & Configurations for ISF-7200R
-
Universal Platform (755 × 520 mm)
-
Flask Clamps (Stainless steel or plastic, 50 mL to 6 L)
-
Funnel Clamps (250 mL to 2 L)
-
Spring Wire Rack
-
Test Tube Racks (Ø8 mm to Ø35 mm)
-
Microplate Holders (Single, Tower, Flat A/B)
-
Rubber Mat
-
Universal Attachment
-
Dedicated Platforms (250 mL & 500 mL)
-
Lab Sticker
-
LC GreenBox – for mobile monitoring and alerts
