Gram BioCompact II RF610 Laboratory Freezer
€3.615,00 excl. VAT
The Gram BioLine BioCompact II RF610 is a high-capacity upright laboratory freezer designed for the safe and reliable storage of temperature-sensitive materials down to -25 °C. With a spacious 601 L gross volume and net storage of 507 L, it meets the needs of research institutions and laboratories requiring robust and energy-conscious cold storage. Its ATEX Cat. 3 Zone 2 compliance ensures safe use in potentially explosive environments. The efficient forced air distribution system, sturdy interior design, and minimal energy consumption (1.74 kWh/24h) make this freezer a dependable and cost-effective choice.
High-Capacity Laboratory Freezer for Demanding Environments
The Gram BioLine BioCompact II RF610 is a robust -25 °C laboratory freezer built to meet the rigorous demands of scientific and medical facilities. With its expansive 601-liter gross volume and highly efficient BioLine air circulation system, it guarantees consistent temperature distribution and safe storage for biological samples, reagents, and other sensitive materials. This model combines high-performance freezing with energy efficiency, consuming just 1.74 kWh/24h, and meets ATEX Category 3 Zone 2 safety standards—making it ideal for laboratories that require explosion protection.
Its durable construction, flexible shelving, and user-friendly controls make the RF610 a top choice for professionals seeking a reliable and compliant cold storage solution.
Warranty: 1 year
Lead time: 2 weeks
Specifications Gram BioCompact II RF610 Lab Freezer
| Temperature range | -25 °C/-5 °C |
| Ambient temperature range | +10 °C/+43 °C |
| Control unit | Gram Control Unit with voltage free contact, alarms and offset function |
| Alarms | Acoustic and visual, High/Low temperature alarms and door alarm |
| Access port | 1 pcs. Ø 24.5 mm |
| Material interior | PS lining with wall rails in stainless steel |
| Material exterior | White lacquered steel or stainless steel finish |
| Dimensions (WxDxH) | 695 x 875 x 1874/2075* |
| Net weight | Unpackaged net weight without optional fittings: 114 kg |
| Gross volume | 583 litres |
| Net volume | 513 litres |
| Modules for shelves and drawers | Shelves 24 – Drawers 12 |
| Insulation | 60 mm polyurethane with HFC-free cyclopentane propellant |
| K-Value | Solid door 0.31 W/m²K |
| Refrigerant | R290 |
| Refrigerant charge | 92 g |
| Refrigeration capacity at -25°C | R290 512 Watt |
| CO2e | – |
| Energy consumption (kWh/24h) (R290) | 4.05 |
| Heat emission (Watt) (R290) | 472,24** |
| Connection | 230 V, 50 Hz |
| Connection load (Watt) (R290) | 485 |
| Start current (R290) | 13,1 A |
| Sound level | 48.6 dB(A) |
| Air system | BioLine ventilated air distribution system |
| Defrost system | Automatic smart defrost with re-evaporation of defrost water |
Options Gram BioCompact II RF610 Lab Freezer
- Aluminium drawers
- ABS drawers
- Perforated stainless steel shelf
- Stainless steel – wire shelf
- plastic white coated wire shelf
- Wire basket
- Refference container
- Legs, castors or plinths
- Wall mounting
- Chart recorder
- Low temperature protection
- Stainless steel exterior
- On-site qualification
- IQ OQ
- PQ
