Scientz-4TD Multi-Channel Ultrasonicator
Scientz-4TD Multi-Channel Ultrasonicator
€11.968,33 excl. VAT
The Scientz-4TD is a multi-channel ultrasonicator designed for laboratories that need to process multiple small samples at the same time. Equipped with 4 ultrasonic probes, it allows simultaneous processing of 1–20 ml samples with strong consistency between sample positions. The system is ideal for applications such as cell disruption, homogenization, emulsification, extraction and dispersion in bioengineering, pharmaceutical, environmental and food research. With 2400 W ultrasonic power, adjustable output from 1–100% and selectable gap or continuous operation, the Scientz-4TD provides flexible control for repeatable workflows. It includes touchscreen operation, program storage and a soundproof box, making it a practical multi-channel ultrasonic homogenizer for laboratories that need higher throughput than single-probe systems.
Multi-Channel Ultrasonicator for 4-Sample Processing
The Scientz-4TD is designed for laboratories that need consistent ultrasonic processing of several small samples in parallel. It is particularly suitable for research teams working with repeated sample preparation protocols where reproducibility, speed and sample-to-sample consistency are important.
- Processes 4 samples simultaneously
- Suitable for 1–20 ml sample volumes
- Ideal for cell disruption, homogenization, extraction and emulsification
- Gap or continuous pulse modes for flexible method development
- Choose this model when a single-probe ultrasonicator is too slow, but high-density multiwell processing is not required
Scientz-4TD Multi-Channel Ultrasonicator for Parallel Sample Processing
The Scientz-4TD is a multi-channel ultrasonic homogenizer developed for laboratories that need to process multiple samples at the same time. Unlike a conventional single-probe ultrasonicator, the Scientz-4TD uses 4 probes to treat several samples simultaneously, improving throughput and consistency in repeated workflows.
This makes the system particularly useful for laboratories working with parallel biological, pharmaceutical, environmental or materials samples.
4 Probes for Simultaneous Ultrasonic Homogenization
The main advantage of the Scientz-4TD is its 4-probe configuration. Each probe can process samples from 1 ml to 20 ml, allowing users to run four comparable samples in the same ultrasonic cycle.
This reduces manual handling, improves efficiency and helps maintain more consistent treatment conditions between samples.
2400 W Ultrasonic Power with Adjustable Output
The Scientz-4TD provides 2400 W ultrasonic power with adjustable output from 1–100%. The Ø6 mm probe diameter is suitable for small-volume sample disruption, homogenization and dispersion.
The system supports both gap and continuous working modes, allowing users to adapt the ultrasonic program to heat-sensitive samples, biological materials or more intensive disruption applications.
Intelligent Control and Program Storage
The Scientz-4TD includes touchscreen operation and intelligent storage for up to 20 operating programs. This helps laboratories repeat frequently used methods and standardize ultrasonic processing across different operators.
Key control features include:
- 7-inch TFT display
- Touchscreen operation
- 20 stored programs
- Gap or continuous working mode
- Adjustable pulse settings from 0.1–99.9 seconds
- Temperature sensor
- Self-diagnostic function
- Overload and over-temperature protection
Ideal Applications
The Scientz-4TD is ideal for laboratories that need a multi-channel ultrasonicator for repeated processing of small samples.
Ideal use cases include:
- Parallel cell disruption
- Bacterial and tissue homogenization
- Emulsification of multiple samples
- Extraction workflows
- Sample preparation before analysis
- Small-volume pharmaceutical research
- Environmental sample preparation
- Food and bioengineering applications
Choose the Scientz-4TD when:
- You need to process 4 samples simultaneously
- You work with 1–20 ml sample volumes
- You want better throughput than a single-probe ultrasonic homogenizer
- You need strong consistency between parallel samples
- You do not need the higher probe count of the 6TD, 8TD, 16TD or multiwell-oriented models
Scientz Value Proposition
The Scientz-TD series extends ultrasonic homogenization from single-sample processing to parallel sample workflows. For laboratories that process repeated sample sets, the Scientz-4TD offers a practical balance between throughput, control and reproducibility.
Scientz ultrasonicators combine strong ultrasonic performance with user-friendly touchscreen control, broad application flexibility and excellent value for laboratories looking for a multi-channel ultrasonic homogenizer.
Technical Specifications – Scientz-4TD
| Specification | Scientz-4TD |
|---|---|
| Product Type | Multi-channel ultrasonicator / multi-channel ultrasonic homogenizer |
| Ultrasonic Power | 2400 W |
| Frequency | 20 kHz ± 0.5 |
| Number of Tips / Probes | 4 |
| Crushing Capacity | 1–20 ml |
| Power Adjustable | 1–100% |
| Tip Diameter | Ø6 mm |
| Working Mode | Gap / continuous |
| Pulse | Adjustable 0.1–99.9 s, gap / working |
| Temperature Sensor | Yes |
| Operation Mode | Touch control |
| Display Mode | 7-inch TFT |
| Display Content | 7 display types including temperature, power, pulse mode and time |
| Protection Device | Self-diagnostic function, automatic error correction, overload protection and over-temperature protection display |
| Storage Data | 20 groups |
| Soundproof Box | Yes |
Options and Accessories – Scientz-4TD
The Scientz-4TD is configured with 4 ultrasonic probes for simultaneous processing of 1–20 ml samples. It is designed for parallel small-sample workflows where consistent processing across multiple samples is important.
| Accessory | Description |
| Ø6 mm probes | Standard probe diameter for 1–20 ml sample processing |
| Sample holders | For positioning multiple small sample vessels |
| Suitable tubes / vessels | For parallel ultrasonic treatment of small samples |
Available options and accessories:
- Ø6 mm ultrasonic probes
- Sample holders for multi-sample processing
- Suitable tubes and sample vessels
- Application-specific setup support for repeated sample workflows
