Gram BioPlus ER1400 Laboratory Refrigerator
Gram BioPlus ER1400 Laboratory Refrigerator
Pricing on request
The Gram BioPlus ER1400 is a high-capacity laboratory refrigerator designed for sensitive laboratory, pharmaceutical and biotech applications. With a gross volume of 1400 litres and a net capacity of 968 litres, it ensures uniform temperature distribution through the trusted Gram BioLine air system. Its energy-efficient design (only 2.56 kWh/24h) and ATEX Cat. 3 Zone 2 certification make it an ideal solution for storing both biological and flammable reagents and materials in laboratory and GMP environments. Stainless steel interior and robust temperature control features ensure operational safety and long-term performance.
High-Capacity Laboratory Refrigerator for Lab and GMP Applications
The Gram Bioline BioPlus ER1400 delivers uncompromising performance for pharmaceutical and laboratory grade cold storage. This model combines precision temperature control, energy efficiency, and top-tier safety features into a large-capacity cabinet designed for demanding laboratories. Its integrated ATEX Cat. 3 Zone 2 compliance allows for secure storage of both biological and flammable substances. Built with durable stainless steel and intelligent Gram Control Unit, the ER1400 supports consistent storage conditions and full traceability in regulated environments.
Warranty: 1 year
Lead time: 2 weeks
Specifications Gram Bioline BioPlus ER1400
| Temperature range | -2 °C/+20 °C |
| Ambient temperature range | Solid door +10 °C/+43 °C; glass door +10 °C/+38 °C |
| Control unit | Gram Control Unit with voltage free contact, E-sensor, dry cooling and offset function |
| Alarms | Acoustic and visual, High/Low temperature alarms and door alarm |
| Access port | 1 pcs. Ø 24.5 mm |
| Material interior | Stainless steel |
| Material exterior | White lacquered steel or stainless steel |
| Dimensions (WxDxH) | 1390 x 876 x 2025/2275* |
| Net weight | Unpackaged net weight without optional fittings: 283 kg |
| Gross volume | 1400 litres |
| Net volume | 968 litres |
| Modules for shelves and drawers | Shelves 54 – Drawers 26 |
| Insulation | 60 mm polyurethane with HFC-free cyclopentane propellant |
| K-Value | Solid door 0.31 W/m²K; glass door 0.50 W/m²K |
| Refrigerant | R290/prepared for external compressor/prepared for glycol |
| Refrigerant charge | 110 g |
| Refrigeration capacity at -10°C | R290 946 watt |
| CO2e | – |
| Energy consumption (kWh/24h) (R290) | Solid door: 2.56 / Glass door: 3.72 | Dual comp. solid door: N/A / Dual comp. glass door: 4.47 |
| Heat emission (Watt) (R290) | Solid door: 537,63 / Glass door: 539,1 | Dual comp. solid door: N/A / Dual comp. glass door: 769,38** |
| Connection | 230 V, 50 Hz |
| Connection load (Watt) (R290) | 596 | Dual comp. 838 |
| Start current (R290) | 13,2 A |
| Sound level | 47.5 dB(A) |
| Air system | BioLine ventilated air distribution system |
| Defrost system | Automatic smart defrost with re-evaporation of defrost water |
Options Gram Bioline BioPlus ER1400
- Dual compressor
- Aluminium drawers
- ABS drawers
- Perforated stainless steel shelf
- Stainless steel – wire shelf
- plastic white coated wire shelf
- Wire basket
- Glass door
- Refference container
- Legs, castors or plinths
- Wall mounting
- Chart recorder
- DIN-kit 13277
- Low temperature protection
- IQ OQ
- PQ
