Gram BioCompact II RF410 Laboratory Freezer
Gram BioCompact II RF410 Laboratory Freezer
Pricing on request
The Gram BioCompact II RF410 is a dependable and energy-efficient laboratory freezer designed for stable biomaterial storage at -5 to -25 °C. With a net capacity of 312 L, a uniform air distribution system, and optional interior layouts, this freezer is ideal for scientific and pharmaceutical environments. ATEX Cat. 3 Zone 2 certification ensures safe placement in potentially hazardous lab settings. Its low energy consumption and silent operation (36.6 dB) make it both high-performing and lab-friendly.
Powerful and Safe Laboratory Freezer for Demanding Applications
The Gram BioCompact II RF410 is a high-performance laboratory freezer engineered for precision cold storage and operational safety. Thanks to the unique Gram BioLine air distribution system, it maintains a stable and uniform temperature across its 312-liter storage space, eliminating cold walls that risk sample damage. Built to ATEX Cat. 3 Zone 2 standards, this model ensures secure placement even in areas with occasional explosive atmospheres. Its solid construction, programmable alarms, energy-efficient design, and customization options make it a versatile choice for laboratories that prioritize reliability, safety, and efficiency.
Warranty: 1 year
Lead time: 2 weeks
Specifications Gram BioCompact II RF410 Freezer
| Temperature range | -25 °C/-5 °C |
| Ambient temperature range | +10 °C/+35 °C |
| Control unit | Gram Control Unit with voltage free contact alarm and offset function |
| Alarms | Acoustic and visual, High/Low temperature alarms and door alarm |
| Access port | 1 pcs. Ø 24.5 mm |
| Material interior | PS lining |
| Material exterior | White lacquered steel or stainless steel |
| Dimensions (WxDxH) | 595 x 640 x 1776/1976* |
| Net weight | Unpackaged net weight without optional fittings: 78 kg |
| Gross volume | 346 litres |
| Net volume | 312 litres |
| Modules for shelves and drawers | 25 shelves, 13 drawers and 8 wire baskets |
| Insulation | 50 mm polyurethane with HFC-free cyclopentane propellant |
| K-Value | Solid door 0.35 W/m²K |
| Refrigerant | R600a |
| Refrigerant charge | 47 g |
| Refrigeration capacity at -25°C | R600a 204 watt |
| CO2e | – |
| Energy consumption (kWh/24h) (R600a) | 2.06 |
| Heat emission (Watt) (R600a) | 147.74** |
| Connection | 230 V, 50 Hz |
| Connection load (Watt) (R600a) | 154 |
| Start current (R600a) | 8 A |
| Sound level | 36,6 dB(A) |
| Air system | BioLine ventilated air distribution system |
| Defrost system | Automatic smart defrost with re-evaporation of defrost water |
Options Gram Bioline BioCompact II RF410 Freezer
- Aluminium drawers
- ABS drawers
- Perforated stainless steel shelf
- Stainless steel – wire shelf
- plastic white coated wire shelf
- Wire basket
- Reference container
- Legs, castors or plinths
- Wall mounting
- Chart recorder
- Low temperature protection
- Stainless steel exterior
- On-site qualification
- IQ OQ
- PQ
