Binder KBF 1060 constant climate chamber
€26.981,00 excl. VAT
Benefits:
- A reliable option for critical ICH stability testing thanks to maximum climate homogeneity, even when the unit is fully loaded
- Reliable: failsafe operation over the long term thanks to proven compressor technology and interior made of stainless steel
- Smart: signal triangle with light-up status display and ergonomic control terminal with touchscreen program controller
- Economical: up to 40% lower energy consumption than the previous model thanks to modern inverter cooling technology
Important features:
- Temperature range: 0°C to +70°C
- Humidity range: 10% to 80% RH
- Proven APT.line™ preheating chamber technology
- Up to 40% lower energy consumption compared to the previous model
- Energy-efficient cooling with modern inverter cooling unit
- Cooling with climate-neutral R-600a refrigerant
- Door heating to prevent condensation
- Adjustable fan speed
- Humidity regulation with capacitive humidity sensor and responsive steam humidification
- Robust housing design with HIT sandwich technology
- Stainless-steel inner chamber
- Inner doors made of metal oxide-coated safety glass
- Two racks made of stainless steel
- Large access port with silicone plug
- Floor-standing units (from model 260) featuring robust twin casters, with brakes at the front
- Intuitive touchscreen controller with time-segment and real-time programming
- Ergonomically adjustable control terminal (from model 470)
- Signal triangle with light-up status display (from model 470)
- Internal data logger, measured values can be read out in open format via USB
- Class 3.3 independent temperature safety device (DIN 12880) with visual and acoustic alarms
- Unit self-test for comprehensive status analysis
- Data interfaces: Ethernet, USB
- BINDER Multi Management Software APT-COM™ basic edition
- Optional light modules for ICH photostability testing (for models 260, 470, 720)
- Optional LED light modules for plant growth (for models from 260)
Description
Binder Climate Chamber KBF 1060 – 1 070 L Constant Climate Chamber
The Binder climate chamber KBF 1060 is a high-capacity constant climate chamber engineered for demanding ICH-compliant stability and shelf-life testing in pharmaceutical, biotech, and research laboratories. With an expansive 1 070-liter stainless steel interior, this model offers reliable, uniform control of temperature (0 °C to +70 °C) and humidity (10 % to 80 % RH) across the entire chamber volume.
Equipped with Binder’s APT.line™ preheating chamber technology and a modern inverter compressor using R-600a refrigerant, the KBF 1060 ensures exceptionally stable climate conditions with energy consumption reduced by up to 40% compared to previous models.
Its intuitive touchscreen controller supports time-segment programming and GLP-compliant data logging via USB and Ethernet interfaces. Safety features include a Class 3.3 independent temperature safety device, audible and visual alarms, and an integrated diagnostic system for added reliability.
Additional practical features include adjustable fan speed, door heating to prevent condensation, a large 80 mm access port, and a mobile floor-standing design with brakeable casters. Optional lighting modules are also available for photostability testing, further enhancing its versatility.
Key Features:
-
Temperature range: 0 °C to +70 °C
-
Humidity range: 10 % to 80 % RH
-
Internal volume: 1 070 liters
-
APT.line™ preheating technology for uniformity
-
Inverter compressor with R-600a refrigerant
-
Up to 40% energy savings
-
Touchscreen controller with segment programming
-
USB and Ethernet interfaces for data logging
-
Class 3.3 safety system with alarms
-
Built-in diagnostics and system monitoring
-
Door heating and adjustable fan speed
-
Ø 80 mm access port
-
Mobile, floor-standing design with casters
-
Optional lighting modules for photostability
The Binder climate chamber KBF 1060 combines maximum capacity, energy efficiency, and precision, making it an ideal solution for laboratories performing critical stability testing under controlled climatic conditions.
Specifications
Warranty: 2 years
Lead time: 1-2 weeks
| Designation | KBF1060-230V |
| Article Number | 9020-0482 |
| Performance Data Temperature | |
| Temperature range | 0…70 °C |
| Max. heat compensation at 40°C | 640 W |
| Performance Data Climate | |
| Temperature range with humidity | 10…70 °C |
| Humidity range | 10…80 % RH |
| Temperature uniformity at 25°C and 60% RH | 0.3 ± K |
| Temperature uniformity at 40°C and 75% RH | 0.2 ± K |
| Temperature fluctuation at 25°C and 60% RH | 0.1 ± K |
| Temperature fluctuation at 40°C and 75% RH | 0.1 ± K |
| Recovery time after door was opened for 30 s at 25°C and 60% RH | 2 min |
| Recovery time after door was opened for 30 s at 40°C and 75% RH | 5 min |
| Measures | |
| Interior volume | 1,070 L |
| Net weight of the unit (empty) | 340 kg |
| Load per rack | 40 kg |
| Permitted load | 100 kg |
| Doors | |
| Unit doors | 2 |
| Inner doors | 2 |
| Internal Dimensions | |
| Interior width | 1,011 mm |
| Interior height | 1,250 mm |
| Interior depth | 847 mm |
| Wall clearance | |
| Wall clearance back | 100 mm |
| Wall clearance sidewise | 180 mm |
| Housing dimensions not incl. fittings and connections | |
| Width net | 1,285 mm |
| Height net | 1,951 mm |
| Depth net | 1,175 mm |
| Electrical data | |
| Housing protection acc. to EN 60529 | IP 20 |
| Rated Voltage | 220…240 V |
| Power frequency | 50/60 Hz |
| Nominal power | 1,6 kW |
| Nominal current | 6,7 A |
| Unit fuse | 16,0 A |
| Phase (Nominal voltage) | 1~ |
| Environment-specific data | |
| sound level at 25°C + 60 % RH | 52 dB(A) |
| Energy consumption at 25°C and 60% RH | 365 Wh/h |
| Energy consumption at 40°C and 75% RH | 370 Wh/h |
| Fixtures | |
| Number of shelves (std./max.) | 2/16 |
Full list: see datasheet
