Binder UV V 350 ultra-low temperature freezer
€13.184,00 excl. VAT
Benefits:
- Lowest energy consumption in its class
- Environmentally-friendly refrigerants R-290 and R-170
- Thermal insulation with unique long-life VIPs (vacuum insulation panels)
- Rust-proof interior made completely of stainless steel
Important features:
- Temperature range: -90 °C to -40 °C
- Lowest energy consumption in its class
- Powerful cascade compressor cooling unit
- Environmentally friendly refrigerants R-290 and R-170
- Thermal insulation with unique long-life VIPs (vacuum insulation panels)
- Innovative door gasket concept reduces buildup of ice
- Ergonomic door handle
- Rust-proof interior made completely of stainless steel
- Detachable inner doors made of stainless steel
- 3 stainless-steel shelves providing flexible placement
- Zero-voltage alarm contact for in-house alarm system
- Internal data logger, measured values can be read out in open format via USB
- Ethernet interface
- 3 access ports, Ø 28 mm, rear
Description
Binder UF V 350 Ultra Low Temperature Freezer – Secure -90 °C Storage for Sensitive Laboratory Samples
The Binder UF V 350 ultra low temperature freezer is expertly designed to meet the rigorous demands of modern laboratories, offering precise and reliable storage from -90 °C to -40 °C with impressive energy efficiency. Boasting a generous 402 L capacity, this ULT freezer is ideal for preserving valuable biological and chemical samples such as vaccines, enzymes, cell cultures, and more.
Constructed with a stainless steel interior and advanced vacuum-insulated panels (VIPs), the UF V 350 ensures excellent thermal stability and swift temperature recovery after door access. Its cascade refrigeration system, powered by climate-neutral refrigerants (R‑290/R‑170), delivers exceptional performance—while maintaining the lowest energy consumption in its class.
The user-friendly touchscreen interface provides accurate temperature monitoring, data logging, and configurable alarm settings—key for GLP-compliant workflows. Sample safety is further enhanced by multi-level alarms (visual, audible, battery-backed), lockable doors, and three Ø 28 mm access ports for temperature validation or sensor integration.
Key Features:
-
Temperature range: -90 °C to -40 °C
-
402 L stainless steel chamber
-
Vacuum-insulated panels for superior thermal integrity
-
Cascade compressor with low energy use
-
Climate-neutral refrigerants (R‑290/R‑170)
-
Internal data logger with USB export & Ethernet interface
-
Visual & audible alarms plus zero-voltage alarm contact
-
Three Ø 28 mm access ports for validation
-
Lockable door and ergonomic handle
-
Corrosion-resistant stainless steel interior
-
Detachable inner doors and three adjustable shelves
The Binder UF V 350 offers scientists a robust, energy-efficient solution for ultra low temperature storage—perfectly aligned with the demands of research and clinical laboratories.
Specifications
Warranty: 5 years, 12 years on compressors
Lead time: 1-2 weeks
| Designation | UFV350-230V |
| Article Number | 9020-0453 |
| Performance Data Temperature | |
| Temperature range | -90…-40 °C |
| Temperature uniformity at -80°C | 3.5 ± K |
| Temperature fluctuation at -80°C | 4.0 ± K |
| Cooling down time from 22°C to -80°C | 210 min |
| Measures | |
| Interior volume | 402 L |
| Net weight of the unit (empty) | 226 kg |
| Permitted load | 160 kg |
| Doors | |
| Unit doors | 1 |
| Inner doors | 2 |
| Internal Dimensions | |
| Interior width | 486 mm |
| Interior height | 1,300 mm |
| Interior depth | 636 mm |
| Wall clearance | |
| Wall clearance back | 100 mm |
| Wall clearance sidewise | 250 mm |
| Housing dimensions not incl. fittings and connections | |
| Width net | 706 mm |
| Height net | 1,966 mm |
| Depth net | 938 mm |
| Electrical data | |
| Housing protection acc. to EN 60529 | IP 20 |
| Rated Voltage | 230 V |
| Power frequency | 50 Hz |
| Nominal power | 1,6 kW |
| Nominal current | 7,0 A |
| Unit fuse | 10,0 A |
| Phase (Nominal voltage) | 1~ |
| Environment-specific data | |
| Sound-pressure level | 47 dB(A) |
| Energy consumption at set value -80°C and Ta = 20°C | 7.5 kWh/d |
| Fixtures | |
| Number of shelves (std./max.) | 3/11 |
| Load-variants | |
| Freezer racks per compartment | 3 |
| Cryoboxes, 50 mm | 264 |
| Cryoboxes, 75 mm | 168 |
Full list: see datasheet
